Technical Parameters

Specifications All parameters can be produced according to your demands
Model AVS3P 0-115V AVS3P 0-240V
Voltage 115V/127V 230V/240V
Rated Current 16A 16A
Under Voltage Protection 95V(75-115V adjustable) 190V(150-230V adjustable)
Over Voltage Protection 130V(115-150V adjustable) 265V(230-300V adjustable)
Surge Protection 80 Joule 160 Joule
Time-out (Delay Time) 10 Sec-10 Mins(adjustable) 10 Sec-10 Mins(adjustable)
Hysteresis 2V 4V
Mains max spike/surge discharge 6.5kA 6.5kA
Transient suppression Yes Yes
Max operating voltage (Uc) 160V 320V
Socket Aviailablity Direct wiring by screw terminal Direct wiring by screw terminal
