Black Circuit Breaker Series

Black Circuit Breaker Series

Short Description:

For protection against overlood and short circuits in the electrical distribution systemUse in domestic ,commercial and light industrial installations. Conform to IEC 60898,BS 3871. Degree of protection: IP 20


Product Detail

Product Tags

Product Number Ampere rating Rated Voltage(Vac) #of poles
BHP106 6 120/240 1
BHP110 10 120/240 1
BHP116 16 120/240 1
BHP120 20 120/240 1
BHP125 25 120/240 1
BHP130 30 120/240 1
BHP140 40 120/240 1
BHP150 50 120/240 1
BHP160 60 120/240 1
BHP175 75 120/?40 1
BHP1100 100 120/240 1
BHP216 16 120/240 2
BHP220 20 120/240 2
BHP225 25 120/240 2
BHP230 30 120/240 2
BHP240 40 120/240 2
BHP250 50 120/240 2
BHP260 60 120/240 2
BHP275 75 120/240 2
BHP2100 100 120/240 2
BHP350 50 240/415 3
BHP360 60 240/415 3
BHP375 75 240/415 3
BHP3100 100 240/415 3
