Current Limiting Protector manufacturer GQY Over and Under Voltage Electric Current limit switch
MV+MN Self-Recovery Over Under-Voltage Protector
Product Specification
|
MV+MN SELF-RECOVERY OVER UNDER-VOLTAGE PROTECTOR |
|||||
|
Model |
|
HZ |
Over Voltage |
Operating Voltage |
Under Voltage |
|
HWQC-25 |
2P |
50 |
275±5 |
240-260 |
175±5 |
|
HWQC-32 |
|||||
|
HWQC-40 |
|||||
|
4P |
50 |
460±15 |
420-440 |
300±15 |
|
|
HWQC-50 |
|||||
|
HWQC-63 |
|||||
GQY Over and Under Voltage Electric Current Limiting Protector
Application
Over and Under Voltage Electric Current Limiting Protector apply to AC 50HZ, working voltage AC230V control circuit. The electric power supply according to the rated. When the load exceeds the specified value, the controller automatically cut off the power supply of the load, and after time delay automatic reset, connected load power, to realize the automatic detection and control. The product has the advantages of conmpact structure, beautiful appearance.
Basic specification and main parameters: Short circuit, Over current, Under-voltage, Over-voltage, Residual current, Current display, Voltage display, Frequency display, Automatic reset.
