Ground Fault Circuit Interrupters(GFCl)

Ground Fault Circuit Interrupters(GFCl) Featured Image
  • Ground Fault Circuit Interrupters(GFCl)
  • Ground Fault Circuit Interrupters(GFCl)

Ground Fault Circuit Interrupters(GFCl)

Short Description:

Product features
This product can effectively prevent personal electric shock and neutral repeated grounding faults,to protect the safety of human
life and fire accidents.
D It has waterproof and dustproof functions,more reliable,firm and durable.
Output Users can assemble cable by themselves.
D Meet UL943 standard,UL File NO.E353279/Verified by ETL,Control No.5016826.
According to the requirement of California CP65.
D Auto-Monitoring Function
When leakage happens,GFCl will cut ff the circuit automatically.After troubleshooting,it is necessary to manually press the
“Reset”button to restore power to the load.
Product application
O It can apply to various industries,such as house appliance,vacuum cleaners,power tool,lawnmower,cleaning machine,
gardening tool,medical equipment,swimming equipment,refrigerator,food display case,hotel and so on.


Download as PDF

Product Detail

Product Tags

Model Rated
Voltage		 Rated
Current		 Tripping
Current		 Tripping Time
(at I△=264mA)		 Protection
Class		 Cable SPEC Plug SPEC AWG Size
GF01-P3-12 120V~/60Hz 15A 4~6mA ≤25ms UL5E3R(IP54) SJ、SJO、SJOO、
SJOW、SJOOW、
SJT、SJTW、SJTO、
SJTOO、SJTOW、
SJTOOW、HSJ,
HSJO,HSJOO,
HSJOW,HSJOOW		 2P、with grounding
pin(5-15P)		 12AWG
GF01-P3-14 120V~/60Hz 15A 4~6mA ≤25ms UL5E3R(IP54) 2P、with grounding
pin(5-15P)		 14AWG
GF01-P3-16 120V~/60Hz 13A 4~6mA ≤25ms UL5E3R(IP54) 2P、with grounding
pin(5-15P)		 16AWG
GF01-P3-18 120V~/60Hz 10A 4~6mA ≤25ms UL5E3R(IP54) 2P、with grounding
pin(5-15P)		 18AWG
