Application
In the power plant and substation as the DC power supply or emergency power supply.
Features
♦ Easy connection and installation.
♦ Reliable operation.
♦ Maintenance-free.
♦ Un-interrupted power supply could be ensured.
♦ Working conditions
1 Altitude:<2000m(if over,please contact us for solutions)
2 Ambient temperature:-5~+403 Relative humidity:less than 90% in case of 20±5
Note:please contact us for special requirement.
Main features
1 Complete model: The product comprises ten models concerning several hundreds of specifications, fully meeting the need from large-middle-& small-sized power generation plantsubstation and various industries in terms of DC power supply.
2 Reliable operation: Automatic switching of dual input of AC; two charging & floating charge devices for back-up each other.
3 Stable operation: Excellent counter-interference capabilityhigh current and voltage stabilizing accuracy and small ripple cofficient.
4 Long life of battery: The charging and floating charging of storage battery on the base meeting the optimum charging curve avoids over-charging or under-charging. The microcomputer type has the function of patrol inspection to the battery.
5 Mutiple protection: By integrating hardware and software, the product can execute track check to all working points. The check device can arbitraily monitor the insulation condition of busbar.
6 Telecommunication: The microcomputer-controlled DC power supply cubicle can communicate with the superior computer to realize centralized monitor and unattended operation.
HW-YJ Single Phase Emergency Power Supply
Order No./type | Output Power (KW) | Emergency Timo (min) | Ovoral dimensions DxWxH(mm) | Weight (kg) | Output Circuit | Installation |
HW-YJ-0.5KVA | 0.5 | 60 | 230 x 550 x 650 | 60 | 1 | Embedded type Hanging type Floor-type |
90 | 230 x 550 x 650 | 75 | ||||
HW-YJ-1KVA | 1 | 60 | 300 x 600×1200 | 80 | 1 | Embedded type Hanging type Floor-type |
90 | 300 x 600×1200 | 130 | ||||
HW-YJ-1.5KVA | 1.5 | 60 | 300 x 600 x 1200 | 150 | 1 | |
90 | 300 x 600×1200 | 210 | ||||
HW-YJ-2KVA | 2.0 | 60 | 400 x 600×1200 | 215 | 1 | |
90 | 400 x 600×1200 | 230 | ||||
HW-YJ<3KVA | 3.0 | 60 | 400 x 600×1200 | 240 | 1 | Floor-type |
90 | 450 x 750×1500 | 360 | ||||
HW-YJ-4KVA | 4.0 | 60 | 450 x 750×1500 | 320 | 1 | |
90 | 450 x 750×1500 | 460 | ||||
HW-YJ^KVA | 5.0 | 60 | 450 x 750×1500 | 410 | 1 | |
90 | 450 x 750×1500 | 590 | ||||
HW-YJ^KVA | 6.0 | 60 | 630 x 800 x 2000 | 560 | 1 | |
90 | 630 x 800 x 2000 | 750 | ||||
HW-YJ-7KVA | 7.0 | 60 | 630 x 800 x 2000 | 650 | 1 | |
90 | 630 x 800 x 2000 | 900 | ||||
HW-YJ-8KVA | 8.0 | 60 | 630 x 800 x 2000 | 750 | 1 | |
90 | 630 x 800 x 2000 | 1000 | ||||
HW-YJ-9KVA | 9.0 | 60 | 630x800x 2000 | 850 | 1 | |
90 | 630 x 800 x 2000 | 1100 | ||||
HW-YJ-10KVA | 10.0 | 60 | 630 x 800 x 2000 | 960 | 1 | |
90 | 630 x 800 x 2000 | 1200 |
