Applications

Type HQP Plug-in Miniature Circuit Breakers Type QC Cable in- Cable out Minlature Circult Breakers

Rating: 10- 100 Amperes, 240/415 Volts,

Calibration at 40 (50 Calibration Available)

Interrupting Ratings: 10kA IC with Main Switch for Main Breakers

Specification

BS3871, Part1.

Modular Circuit Breakers:25mm(1inch) module.

Current Ratings:10 to 100 Amps;1,2 and 3poles.

Therma-Magnetic Design.

Maximum operating voltages 240/415 Vac Toggle Handle indicates”ON OFF* and TRIPPED positions, THp free mechanism in every pole.

AII multi-pole breakers incorporate intemal common trip mechanism. Ampere atings clearlyvisible on handles.

All ferrous metal parts plated to resist corrosion.

No intermal aluminum parts.

AB DE- 10N Arc Extinguishers in every pole, Steel frame construction used in every pole.
