waterproof connector 2Pin 3 pin 4 pins Quick installation without screws 32A 24A PA66 IP68 nickel plated brass wire connector

Short Description:

waterproof wire connector


Product Detail

Product Tags

Waterproof Connector

Model: HW- M20-2P

Number of Poles: 2Pin

Voltage Rating :250V

Current Rating:32A

Wire Section:0.08mm2 -2.5mm2

Min WireSizeOD :5 9mm, 7-10.5mm

Temperature Rating:-40″C-+105°C

IP Code :IP68

Housing Materials: PA66

Contact/Terminal Material:Nickel Plated Brass

Model: HW- M25-3P

Number of Poles :3Pin

Voltage Rating :250V

Current Rating:32A

Wire Section:0.08mm2-2. 5mm2

Min Wire Size OD :6-12mm

Temperature Rating:-40*C-+105″C

IP Code :IP68

Housing Materials:PA66

Contact/Terminal Material :Nickel-Plated Brass

Model:KJS-L16-2P/3P

Number of Poles :2Pin/3Pin

Voltage Rating :450V

Current Rating: 24A

Wire Section:0.08mm2-1. 5mm2

Min Wire Size OD :4- 8mm

Temperature Rating:-40″C-+105°C

IP Code :IP68

Housing Materials:PA66

Contact/Terminal Material:Nickel- Plated Brass



Model:KJS-L20-2P/3P/4P

Number of Poles :2Pin/3Pin/4Pin

Voltage Rating :450V

Current Rating: 24A

Wire Section:0.08mm2-2. 5mm2

Min Wire Size OD :4-7mm, 6-10.5mm

Temperature Rating:-40″C-+105°C

IP Code :IP68

Housing Materials :P A66

Contact/Terminal Material : Nickel- Plated Brass

Model:KJS-PG9-2P

Specifications

Number of Poles:2Pin

Voltage Rating :400V

Current Rating: 24A

Wire Section:0.08mm2 1.5mm2

Min Wire Size OD :4- 8mm

Temperature Rating:-40″C-+105°C

IP Code :IP68

Housing Materials: PA66

Contact/Terminal Material: Nickel- Plated Brass
