MCB Miniature circuit breaker for 4 pole 100 125 amp MCB price of a circuit breaker

Short Description:

Construction features The product conforms to the standards of IEC60947-2.

♦It can be used for the connection with wires 35mm2or less.

♦It has the advantage of small volume and high breaking capacity, and visible contact close indicator can be used for separating the circuit.


Product Detail

Product Tags

Scope of application

♦S7D series circuit breakers have the advantages of small apperance, light weight, excellent and reliable functions, higher breaking capacity, rapid tripping and long life.
♦As for the guide installation, case and partes, they adopt high resistance and impact resistance plastics.
♦They are mainly applied to the AC 50Hz/60Hz circuit with rated operation volage 415V or less provid circuits with overload and short-circuit protections, and to make and break the electrical device and lighting circuit infequently.
♦The product can be installed with undervoltage release and shunt release, and also can be used for separating, and protecting the undervoltage of the circuit and breaking the long distance.

Main technical parmeters
Model Rated current A Poles Ue(V) Breaking capacityA
C 63  80  100 1 240/415 10000
2 3 4 415
D 63  80  100 1 240/415
2 3 4 415
