transformer single phase pole mounted transformer overhead transformer supply for daily lighting
Application
The Yuanky overhead transformer may be used alone for the supply of a single phase load or as one of three units in a bank for the supply of a three phase load. Our single phase overhead distribution transformer is commonly used in various places including rural areas, remote regions and scattered villages to provide high quality power supply for daily lighting, agricultural production and industrial plants. grid.etc
Standards
IEEE & ANSI C57 12.00,IEEE & ANSI C57 12.20,IEEE & ANSI C57 12.90
Product range
-kVA:10 through 500
-Temperature rise:65C
-Cooling type:ONAN
- Single phase-Hert:60&50
- Polarity:Additive or subtractive
- Primary voltage:2400V through 34500GrdY/19920V
- Secondary voltage: 120/240V,240/480V, 139/277V,600V
-Taps:±2X2.5% HV side
