YUANKY TIME RELAY 1S 3S 6S 10S multi-period DPDT SPDT 12v 24v AC/DC12-240V time relay

Short Description:

Time relay is an automatic control unit, which can be combined with various other electrical equipment to realize automatic control of the running circuit. When a preset time is over, the contact output will be closed or opened, so that the terminal electrical equipment can run or stop automatically.

This series of time relay has the advantages of wide operating voltage range, clear working instructions, small volume, uniform size, easy installation, etc.

Application

Industrial machinery

illumination

Manufacturing

HVAC system

Food and agriculture


Product Detail

Product Tags

time relay-a

Technical Data

HW521T

HW522T

HW541T

HW542T

Output Characteristics

Multi-period SPDT Output

Multi-period DPDT Output

Multi-period Circulation, SPDT

Multi-period Circulation, DPDT

Rated Current

5A/16A

Working Voltage

Single Voltage: AC12V,AC24V,AC110V,AC220V,DC12V,DC24V

Wide Voltage: AC/DC12-240V

Time Range

0.1S-10D

Functions



Dimensions: in(mm)

Wiring Diagrams











Technical Data

HW5110

HW5111

HW5120

HW5121

Output Characteristics

SPDT (On Delay)

DPDT (Off Delay)

DPDT (On Delay)

DPDT (Off Delay)

Rated Current

5A/16A

Working Voltage

Single Voltage: AC12V,AC24V,AC110V,AC220V,DC12V,DC24V

Wide Voltage: AC/DC12-240V

Time Range

1S,3S,6S,10S,30S,60S,3M,6M,10M,30M,60M,3H,6H,10H,30H

Customized according to clients ‘ requirements

Functions







Dimensions: in(mm)

Wiring Diagrams









Technical Data

HW5130

HW521

HW522

HW532

Output Characteristics

One Group Inst, One Group Delay, DPDT

Multi-period Time delay SPDT

Multi-period Time delay DPDT

Multi-period Time delay A/B mode can be switched

Rated Current

5A/16A

Working Voltage

Single Voltage: AC12V,AC24V,AC110V,AC220V,DC12V,DC24V

Wide Voltage: AC/DC12-240V

Time Range

1S,3S,6S,10S,30S,60S,3M,6M,10M,30M,60M,3H,6H,10H,30H Customized according to clients ‘ requirements

A;1S/10S/1M/10M  B:3S/30S/3M/30M  C:6S/60S/6M/60M  D:1M/10M/1H/10H  E:3M/30M/3H/30H

Functions







Dimensions: in(mm)

Wiring Diagrams
